PreSonus Studio 26c USB錄音介面

PreSonus Studio 26c USB錄音介面

PreSonus Studio 26c USB錄音介面

詳細規格：

一般

Sample Rates（取樣率）：44.1, 48, 88.2, 96, 176.4, or 192 kHz

Converter Resolution（轉換器訊號解析度）：24 bit

ADC Converter Dynamic Range（類比數位轉換器動態範圍）：114 dB

DAC Converter Dynamic Range（數位類比轉換器動態範圍）：114 dB

麥克風輸入

Maximum Level（最大音量）：+4.5 dBu (balanced, min gain)

Gain Range（增益範圍）：70 dB

Frequency Response（頻率響應）：20 Hz – 20 kHz (±0.1 dB, min gain, 48 kHz)

Dynamic Range（動態範圍）：110 dB (A-wtd, min gain)

THD + N（總諧波失真＋雜訊）：0.004% (1 kHz, -1 dBFS, min gain)

EIN：-125 dBu (A-weighted, 150Ω, max gain)

Input Impedance（輸入阻抗）：1.6 kΩ

Phantom Power（幻想電源）：+48 VDC (10 mA total)

樂器輸入

Maximum Level（最大音量）：+14 dBu (min gain)

Gain Range（增益範圍）：70 dB

Frequency Response（頻率響應）：20 Hz – 20 kHz (±0.15 dB, 48 kHz, min gain)

Dynamic Range（動態範圍）：110 dB (A-wtd, unity gain)

THD + N（總諧波失真＋雜訊）：0.008% (1 kHz, min gain)

Input Impedance（輸入阻抗）：1MΩ

主要輸出

Type（插孔規格）：6.3 mm TRS, Female

Maximum Level（最大音量）：+10 dBu (1 kHz, unity gain, balanced)

Frequency Response（頻率響應）：20 Hz – 20 kHz (±0.1 dB, unity gain, 48 kHz)

Dynamic Range（動態範圍）：108 dB (unity gain, unwtd)

THD + N（總諧波失真＋雜訊）：0.0015% ( 1 kHz, -1 dBFS, unity gain)

輸出（3/4）

Type（插孔規格）：6.3 mm TRS, Female

Maximum Level（最大音量）：+10 dBu (1 kHz, unity gain, balanced)

Frequency Response（頻率響應）：20 Hz – 20 kHz (±0.1 dB, unity gain, 48 kHz)

Dynamic Range（動態範圍）：113 dB (unity gain, unwtd)

THD + N（總諧波失真＋雜訊）：0.008% ( 1 kHz, -1 dBFS, unity gain)

耳機輸出

Maximum Power（最大功率）：30 mW / channel @ 56Ω

Frequency Response（頻率響應）：20 Hz – 20 kHz (±0.2 dB, 56Ω load, 48 kHz)

Dynamic Range（動態範圍）：104 dB (A-wtd, 56Ω load)

THD + N（總諧波失真＋雜訊）：0.009% (1 kHz, 0 dBFS, loaded)

Impedance Working Range（阻抗工作範圍）：32Ω to 300Ω

粉絲頁直接詢問 :

回首頁

PreSonus Studio 26c USB錄音介面

PreSonus Studio 26c USB錄音介面

Created with the needs of DJs and electronic musicians in mind, the Studio 26c delivers excellent audio quality with professional metering and flexible monitoring options. With two of PreSonus’ pristine XMAX-L mic preamps for recording vocals and custom samples; both MIDI I/O and line inputs for your favorite synths; plus professional input and output metering so you can keep track of your recording and performance levels, the Studio 26c delivers amazing sound quality in a rugged, compact form factor. A complete recording studio right out of the box, the Studio 26c audio interface comes with a complimentary license of PreSonus’ award-winning Studio One® Artist music production software, so you can get creating right away.

---
